BRAKE SHOE » FN2286

FN2286

Specification

Radius
112
Width
55
Thickness
6.7
Pcs In Set
4

Cross Reference

AKEBONO
NR-1034
KASHIYAMA
K2286
TOYOTA
04494-25040
TOYOTA
04495-25020
TOYOTA
04497-25020
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Dyna

08.85~05.95 2000 3Y YY52 RN1264V PN1212 FN2286FN2275FN2260 FN2298
10.96~05.99 2800 3L LY121 RN1358V PN1237 FN2286FN2275 FN2298FN2300
10.96~05.99 2800 3L LY131 RN1358V PN1237 FN2286FN2275 FN2298
05.95~05.99 2800 3L LY201 RN1264V PN1212 DN1251 FN2260FN2286FN2275 FN2298
11.85~05.95 2800 3L LY51 RN1264V PN1212 FN2286FN2275 FN2298
01.86~01.96 2800 3L LY61 RN1264V PN1212 FN2286FN2297 FN2298
09.06~02.15 3000 1KD-FTV KDY221R RN1535V PN1237 DN1214 FN2305FN2286
07.10~ 3000 1KD-FTV KDY231 RN1535V PN1237 DN1214 FN2286FN2296FN2305FN2297FN2366 FN2298
09.07~ 3000 1KD-FTV KDY231L RN1535V PN1237 FN2286FN2296 FN2298
05.99~07.01 3000 5L LY122 RN1535V PN1237 FN2286FN2362 FN2298
05.99~07.01 3000 5L LY132 RN1535V PN1237 FN2286FN2362 FN2298
05.99~07.01 3000 5L LY212 RN1265VRN1264V PN1212 FN2286FN2362FN2297 FN2298

TOYOTA   »   Dyna 150

01.95~01.01 2800 3L LY211R RN1264V PN1212 FN2286 FN2298
09.06~ 3000 1KD-FTV KDY231R RN1535V PN1237 FN2286 FN2298
01.95~10.01 3000 5L-E LY212R RN1264VRN1265V PN1212 FN2286FN2297FN2275 FN0015FN2298
07.01~ 3000 5L-E LY235R RN1264V PN1237 FN2286FN2275 FN2298

TOYOTA   »   DYNA 150/TOYOACE G15

10.96~07.01 2000 3Y YY121 RN1358VRN1535V PN1237 FN2286FN2275 FN2298
10.96~07.01 2000 3Y YY131 RN1358VRN1535V PN1237 FN2275FN2286 FN2298FN2300
05.95~07.01 2000 3Y YY201 RN1264V PN1212 DN1251 FN2286FN2260FN2275 FN2298
05.95~07.01 2000 3Y YY211 RN1264V PN1212 FN2286FN2275 FN2298
05.95~05.99 2800 3L LY211 RN1265VRN1264V PN1212 FN2286FN2275FN2297 FN2298
