ROTOR DISC » RN1264V

Specification

Type

Vented

Disc Thickness (Max)

25

Num. of holes

6

Height

51.4

Centering Diameter

91

Pitch Circle Ø

120

Front/Rear

Front

Outter Ø

258

Drum Ø:

132

Disc Thickness (Min)

23

Structure Material

G3000

Cross Reference

TOYOTA

43512-25020

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Dyna

08.85~08.87	1600	1Y	YY50	RN1264V	PN1212	DN1251	FN2276 FN2260 FN2275	FN2298
08.87~09.93	1800	2Y	YY51	RN1264V	PN1212	DN1251	FN2275 FN2260 FN2276	FN2298
08.85~05.95	2000	3Y	YY52	RN1264V	PN1212		FN2260 FN2286 FN2275	FN2298
08.85~12.95	2000	3Y	YY61	RN1264V RN1265V	PN1212		FN2297 FN2275	FN2298
08.87~05.95	2400	2L	LY50	RN1264V	PN1212		FN2260 FN2276
08.85~08.88	2400	2L	LY60	RN1264V RN1265V	PN1212		FN2297 FN2275	FN2298
05.95~05.99	2800	3L	LY201	RN1264V	PN1212	DN1251	FN2286 FN2275 FN2260	FN2298
11.85~05.95	2800	3L	LY51	RN1264V	PN1212		FN2275 FN2286	FN2298
01.86~01.96	2800	3L	LY61	RN1264V	PN1212		FN2286 FN2297	FN2298
05.99~07.01	3000	5L	LY212	RN1264V RN1265V	PN1212		FN2362 FN2297 FN2286	FN2298

TOYOTA » Dyna 150

01.95~01.01	2800	3L	LY211R	RN1264V	PN1212		FN2286	FN2298
01.95~10.01	3000	5L-E	LY212R	RN1265V RN1264V	PN1212		FN2275 FN2286 FN2297	FN2298 FN0015
07.01~	3000	5L-E	LY235L	RN1264V	PN1237		FN2275	FN2298
07.01~	3000	5L-E	LY235R	RN1264V	PN1237		FN2286 FN2275	FN2298

TOYOTA » DYNA 150/TOYOACE G15

05.95~07.01	2000	3Y	YY201	RN1264V	PN1212	DN1251	FN2260 FN2275 FN2286	FN2298
05.95~07.01	2000	3Y	YY211	RN1264V	PN1212		FN2275 FN2286	FN2298
05.95~05.99	2800	3L	LY211	RN1264V RN1265V	PN1212		FN2275 FN2297 FN2286	FN2298
