BRAKE SHOE » FN11909

Specification

Radius
89
Width
37
Pcs In Set
4
Thickness
5.5

Cross Reference

FMSI
S749
HYUNDAI
58305-25A00
KASHIYAMA
K11165
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.99~07.02 1300 G4EA CG 5DR HB RHD RN1221V PN0091 DN1473DN1471 FN11189FN11909
09.99~07.02 1300 G4EA CG SDN LHD RN1221V PN0091 DN1473DN1471 FN11189FN11909
09.99~07.02 1300 G4EA HB LHD RN1221V PN0091 DN1471DN1473 FN11189FN11909
01.00~07.02 1300 G4EH LC RN1221V PN0091 DN1473DN1471 FN11189FN11909
04.02~06.06 1500 D3DA C# RN1027V PN0091 FN11909
04.02~06.06 1500 D3EA LC PN0091 FN11909
09.99~10.02 1500 G4#K CF RN1027V PN0091 FN11909
09.99~07.02 1500 G4#K CG RN1027V PN0091 DN1473DN1471 FN11909FN11189
07.99~04.03 1500 G4EB CH LHD RN1221V PN0091 DN1471 FN11909
09.99~07.02 1500 G4EB CH RHD RN1221V PN0091 DN1471DN1473 FN11189FN11909
03.01~07.02 1500 G4EB LC (RUS) RN1221V PN0091 DN1473DN1471 FN11909FN11189
04.01~07.02 1500 G4EC-G LC (RUS) RN1221V PN0091 DN1473DN1471 FN11909FN11189
01.00~06.06 1600 G4ED LC RN1221V PN0091 DN1471DN1473 PN0436FN11909FN0617
01.00~01.04 1600 G4ED-G LC RN1027V PN0091 FN11909
01.99~07.02 1300 G4EA CG41 RN1221V PN0091 DN1473DN1471 FN11909FN11189
03.01~03.06 1500 D3EA LC PN0091 FN11909
01.00~06.06 1600 G4ED LC RN1221V PN0091 DN1473DN1471 FN0617PN0436FN11909

Exemption from liability: the catalog data is advisory and can be used for reference only
