ROTOR DISC » RN2121

Specification

Type
Solid
Outter Ø
253
Num. of holes
5
Disc Thickness (Max)
10
Disc Thickness (Min)
8
Height
61.3
Centering Diameter
65
Pitch Circle Ø
112
Drum Ø:
140
Front/Rear
Rear
Structure Material
G3000

Cross Reference

VAG
5Q0 615 601 C
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.12~11.20 1000 CHZD 5E__B_ RN1374V PN33005W RN2121 PN0019W
05.14~10.20 1400 CZDA NL3_M RN1374V PN33005W RN33005RN2121 PN0019W
01.17~10.20 1500 DADA 5E__N_ RN1374V PN33005W RN2121 PN0019W
11.12~11.20 2000 CRVC 5E3 RN1377VRN1374V PN33005W RN2121RN33005 PN0019W

Exemption from liability: the catalog data is advisory and can be used for reference only
