NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1256V

ROTOR DISC » RN1256V

Specification

Type

Vented

Disc Thickness (Max)

22

Num. of holes

5

Height

38.6

Centering Diameter

69

Pitch Circle Ø

114.3

Front/Rear

Front

Outter Ø

285

Disc Thickness (Min)

20.4

Drum Ø:

145

Structure Material

G3000

Cross Reference

MITSUBISHI

MR334996

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MITSUBISHI » Pajero IO

11.98~03.05	1600	4G18	H65W GEN LHD	RN1256V	PN3417	DN1358	FN6723
11.98~03.05	1600	4G18	H65W GEN RHD	RN1256V	PN3417	DN1358	FN6723
08.99~05.00	1800	4G93	H61W	RN1256V	PN3417	DN1358	FN6723
03.98~09.02	1800	4G93	H66W	RN1256V	PN3417	DN1358	FN6723
08.99~06.00	1800	4G93	H71W	RN1256V	PN3417	DN1358	FN6723
03.98~06.07	1800	4G93	H76W	RN1256V	PN3417	DN1358 RN1242	FN6723 PN3174	FN0808
06.98~06.07	1800	4G93	H76W JPN	RN1256V	PN3417	DN1358	PN3174 FN6723	FN0808
05.00~09.02	2000	4G94	H62W	RN1256V	PN3417	DN1358	FN6723
05.00~07.04	2000	4G94	H67W	RN1256V	PN3417	DN1358	FN6723
05.00~09.02	2000	4G94	H72W	RN1256V	PN3417	DN1358	FN6723
05.00~06.07	2000	4G94	H77W	RN1256V	PN3417	DN1358	FN6723
02.00~12.05	2000	4G94	H77W GEN	RN1256V	PN3417	DN1358	FN6723
05.00~06.07	2000	4G94	H77W JPN	RN1256V	PN3417	DN1358	FN6723

MITSUBISHI » Pajero Pinin

07.00~01.04	2000	4G94	H67W	RN1256V	PN3417	RN1242	PN3174	FN0808
09.00~02.05	2000	4G94	H77W	RN1256V	PN3417	RN1242	PN3174	FN0808
