NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1205V

ROTOR DISC » RN1205V

Specification

Type

Vented

Disc Thickness (Max)

20

Num. of holes

4

Height

49.9

Centering Diameter

60

Pitch Circle Ø

100

Front/Rear

Front

Outter Ø

246

Drum Ø:

125

Structure Material

G3000

Disc Thickness (Min)

18

Cross Reference

BENDIX

562179B

SUZUKI

5531162G00

SUZUKI

5531162G00000

SUZUKI

5531162G01

SUZUKI

5531162G02

SUZUKI

5531162G02000

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUZUKI » Aerio

11.01~03.07	1500	M15A	RA21S	RN1205V	PN9461		FN0032
01.01~06.06	1500	M15A	RB21S	RN1205V	PN9461		FN0032
01.03~03.07	1600	M16A	RC31S JPN	RN1205V	PN9804	DN1117	FN0032
06.03~12.07	1600	M16A	RH416	RN1205V	PN9461 PN9804	DN1117	FN0032
01.03~03.07	1800	M18A	RC51S	RN1205V	PN9461		FN0032
01.03~06.06	1800	M18A	RD51S	RN1205V	PN9461		FN0032
01.02~12.07	2000	J20A	RC#1H	RN1205V	PN9461		FN0032
11.03~01.08	2300	J23A	RA62S SDN LHD	RN1205V	PN9461		FN0032
01.02~01.08	2300	J23A	RH423	RN1205V	PN9461		FN0032

SUZUKI » Baleno

01.95~12.02

1800

J18A

SY418

RN1205V RN1129V

PN9381 PN2356

PN5198

SUZUKI » Liana

03.01~12.07	1300	M13A	ERA11S SDN	RN1205V	PN9804	DN1117	FN0032
03.01~12.07	1300	M13A	ERC11S HB	RN1205V	PN9804		FN0032
08.04~01.08	1600	M16A	2RC31S HB LHD	RN1205V	PN9461	DN1117	FN0032
01.01~01.08	1600	M16A	ERC31S HB	RN1205V	PN9804	DN1117	FN0032
