NiBK Brakes:: Application Cross Reference and Image for NiBK : BRAKE PADS : PN0297W

BRAKE PADS » PN0297W

Specification

Length-1

94.8

Width-1

48.7

Thickness-1

18.5

Pcs In Set

4

Wire-Sensor

2

Cross Reference

BENDIX AUS

DB1258

BENDIX EUR

571510B

BENDIX EUR

571904B

CITROEN

95666894

FMSI

D454-7334

KASHIYAMA

D11190M

PEUGEOT

425055

PEUGEOT

425087

PEUGEOT

425095

PEUGEOT

425107

PEUGEOT

425135

PEUGEOT

425270

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

CITROEN » ZX

06.92~10.97

2000

XU10J4

N2

RN1004V

PN0297W

PN0270

PEUGEOT » 306

03.93~05.97

2000

XU10J2

PN0297W

FN0512 FN0517 PN0270

PEUGEOT » 405

03.88~12.92	1800	AJZ(XUD7TEY)		RN1004V	PN0297W		PN0019W
07.87~05.97	1900	XU9J#			PN0297W		PN0019W
07.87~08.92	1900	XU9M		RN1004V	PN0297W		PN0019W
07.87~05.97	2000	XU10J2			PN0297W		PN0019W
07.87~05.97	2000	XU10J4Z			PN0297W		PN0019W
