ROTOR DISC » RN2744V

RN2744V

Specification

Type
Vented
Outter Ø
345
Num. of holes
5
Hole Ø:
15.3
Disc Thickness (Max)
22
Disc Thickness (Min)
19.4
Height
56
Centering Diameter
85
Pitch Circle Ø
130
Drum Ø:
179.8
Front/Rear
Rear
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
A 463 423 01 00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MERCEDES-BENZ   »   G 350 d

01.19~03.24 2900 OM 656.929 W463 RN2743V PN0763 RN2744V PN0948

MERCEDES-BENZ   »   G 400 d

07.19~03.24 2900 OM 656.929 W463 RN2743V PN0763 RN2744V PN0948

MERCEDES-BENZ   »   G 450 d

04.24~ 3000 OM 656.830 W465 RN2743V PN0763 RN2744V PN0948

MERCEDES-BENZ   »   G 500

04.24~ 3000 M 256.830 W465 RN2743V PN0763 RN2744V PN0948
03.18~03.24 4000 M 176.980 W463 RN2743V PN0763 RN2744V PN0948
