ROTOR DISC » RN2743V

RN2743V

Specification

Type
Vented
Outter Ø
354
Num. of holes
5
Disc Thickness (Max)
32
Height
56.7
Centering Diameter
85
Front/Rear
Front
Structure Material
G3000
Hole Ø:
15.3
Disc Thickness (Min)
29.4
Pitch Circle Ø
130
Drum Ø:
168.8

Cross Reference

MERCEDES-BENZ
A 463 421 00 00
MERCEDES-BENZ
A 463 421 12 00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MERCEDES-BENZ   »   G 350 d

01.19~03.24 2900 OM 656.929 W463 RN2743V PN0763 RN2744V PN0948

MERCEDES-BENZ   »   G 400 d

07.19~03.24 2900 OM 656.929 W463 RN2743V PN0763 RN2744V PN0948

MERCEDES-BENZ   »   G 450 d

04.24~ 3000 OM 656.830 W465 RN2743V PN0763 RN2744V PN0948

MERCEDES-BENZ   »   G 500

04.24~ 3000 M 256.830 W465 RN2743V PN0763 RN2744V PN0948
03.18~03.24 4000 M 176.980 W463 RN2743V PN0763 RN2744V PN0948
