NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2651V

ROTOR DISC » RN2651V

Specification

Type

Vented

Outter Ø

315

Num. of holes

5

Hole Ø:

16.2

Disc Thickness (Max)

23

Disc Thickness (Min)

21

Height

45

Centering Diameter

67.5

Pitch Circle Ø

120

Drum Ø:

172

Front/Rear

Rear

Structure Material

G3000

Cross Reference

GM

13509676

GM

13528069

GM

13595818

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

BUICK (GM) » Envision

09.20~

2000

LSY

4Z#26

RN2650V

PN52011

RN2651V

PN52014

CADILLAC (GM) » XT4

03.21~	2000	LSQ	6_26	RN2650V	PN52011	RN2651V	PN52014
03.18~	2000	LSY	6_26	RN2650V	PN52011 PN0694	RN2651V	PN52014
