DRUM BRAKE » DN1126

DN1126

Specification

Outter Ø
351
Num. of holes
6
Centering Diameter
108
Height
83
Pitch Circle Ø
139.7
Drum Ø
295
Structure Material
G3000

Cross Reference

TOYOTA
42431-0K180
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Hilux

05.15~ 2400 2GD-FTV GUN135L RN1664VRN1446V PN1482 DN1102DN1126 FN0686FN0620
05.15~ 2400 2GD-FTV GUN135R RN1664VRN1446V PN1482 DN1126DN1102 FN0620FN0686
05.15~ 2500 2KD-FTV KUN135R RN1664V PN1482 DN1126 FN0686
05.15~ 2800 1GD-FTV GUN136R RN1664V PN1482 DN1126 FN0620
05.15~01.18 3000 1KD-FTV KUN126R RN1664V PN1482 DN1126 FN0686
07.05~12.15 3000 5L-E LAN125L RN1319V PN0548 DN1126 FN0686
01.16~ 4000 1GRFE GGN135R RN1664V PN1482 DN1126 FN0686
