ROTOR DISC » RN2031V

RN2031V

Specification

Type
Vented
Outter Ø
254
Num. of holes
6
Disc Thickness (Max)
24
Height
39
Centering Diameter
87
Pitch Circle Ø
108
Drum Ø:
133
Disc Thickness (Min)
22
Front/Rear
Front
Structure Material
G3000

Cross Reference

MITSUBISHI
MB950958
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MITSUBISHI   »   L200

01.96~12.07 2000 4G63 K62T RN2031V PN3369PN2824 DN1339 FN6715FN6718
01.96~01.08 2400 4G64 K65T RN2031V PN2824PN3369 DN1339 FN6715FN6718
01.96~03.06 2500 4D56 K64T RN2031V PN2824 DN1339 FN6718FN6715

MITSUBISHI   »   Triton

06.96~12.07 2800 4M40 K67T RN2031V PN2824PN3369
