ROTOR DISC » RN2017V

Specification

Type
Vented
Outter Ø
234
Num. of holes
4
Disc Thickness (Max)
16
Height
37
Centering Diameter
70
Pitch Circle Ø
88
Drum Ø:
111
Front/Rear
Front
Structure Material
G3000

Cross Reference

DAIHATSU
43512-87220
DAIHATSU
43512-87220-000
DAIHATSU
43512-87222
OEM
4351287222000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.95~09.98 660 EF-# L600S RN2017V PN6295PN6451 FN0027
08.95~09.98 660 EF-# L610S RN2487RN2017V PN6451PN6295 FN0029FN0025FN0036
10.98~10.02 660 EF-# L910S RN2017V PN6427PN6428 FN0020FN0036

Exemption from liability: the catalog data is advisory and can be used for reference only
