ROTOR DISC » RN2006V

RN2006V

Specification

Type
Vented
Outter Ø
273
Num. of holes
5
Disc Thickness (Max)
26
Height
49.5
Centering Diameter
55
Pitch Circle Ø
114.3
Front/Rear
Front
Drum Ø:
129
Disc Thickness (Min)
24
Structure Material
G3000
Hole Ø:
15

Cross Reference

TOYOTA
43512-02260
TOYOTA
43512-02290
TOYOTA
43512-02350
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Corolla

03.08~03.11 1800 1ZZ-FBE ZZE142L RN2006V PN1834 RN2007 PN1835
03.08~11.14 1800 1ZZ-FE ZZE142L RN1576VRN2006V PN1834PN1524 RN2007RN1626 PN1835PN1519
03.11~03.14 1800 2ZR-FBE ZRE142 RN2006V PN1834 RN2007 PN1835
08.13~08.16 1800 2ZR-FE ZRE172L RN2006VRN1576V PN1524PN21001 RN2007RN1626 PN1835PN1519FN2389
03.10~03.14 2000 3ZR-FBE ZRE143 RN2006V PN1834 RN2007 PN1835

TOYOTA   »   Corolla Altis

06.10~12.13 1400 1ND-TV NDE140 RN2006V PN1834 RN2007 PN1835
