MOTORCYCLE BRAKE PADS » PM104

Specification

Length-1
106
Width-1
39
Thick-1
9
Length-2
76.5
Width-2
27
Thick-2
10.5
TYP
R

Cross Reference

KAWASAKI
43082 1125
SUZUKI
69100 22830
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.88~01.07 250 PM529 PM104
01.94~01.96 500 PM104 PM012
01.88~ 250 PM529 PM104
01.87~ 400 PM104 PM529
01.89~ 400 PM104 PM529
01.94~ 500 PM104 PM314
01.88~01.89 250 PM104 PM104
01.90~ 250 PM058 PM104
01.90~01.92 550 PM529 PM104
01.93~ 550 PM104PM529 PM138
01.91~01.95 750 PM529 PM104
01.88~01.89 400 PM104 PM104
01.89~ 250 PM104 PM104
01.90~ 250 PM104 PM104
01.94~01.95 1100 PM529 PM104
01.91~01.92 250 PM058 PM104
01.93~ 250 PM058 PM104

Exemption from liability: the catalog data is advisory and can be used for reference only
