ROTOR DISC » RN1976V

RN1976V

Specification

Type
Vented
Outter Ø
312
Num. of holes
5
Disc Thickness (Max)
18
Height
102.5
Centering Diameter
110
Pitch Circle Ø
150
Drum Ø:
210
Front/Rear
Rear
Disc Thickness (Min)
15
Structure Material
G3000

Cross Reference

TOYOTA
42431-60260
TOYOTA
42431-60261
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Land Cruiser

01.07~ 4000 1GR-FE GRJ71L RN1604V PN1411 RN1976VDN1225 FN1179FN2280FN2306PN1243 FN0642
08.14~07.15 4000 1GR-FE GRJ76K RN1604V PN1411 RN1976V PN1243 FN0642
08.12~ 4000 1GR-FE GRJ78L RN1604V PN1411 RN1976VDN1225 FN1179FN2306FN2280PN1243 FN0642
08.14~05.16 4000 1GR-FE GRJ79K RN1604V PN1411 RN1976V PN1243 FN0642
01.07~ 4000 1GR-FE GRJ79L RN1604V PN1411 RN1976V PN1243FN1179FN2280 FN0642
01.07~ 4000 1GR-FE GRJ79R RN1604V PN1411 RN1976V FN1179FN2306FN2280PN1243 FN0642
01.90~09.23 4200 1H-Z HZJ71L RN1604V PN1411 RN1976VDN1225 FN2306FN1179PN1243FN2280 FN1179FN2280FN0642
08.99~08.04 4200 1H-Z HZJ74 RN1604V PN1411 RN1976V FN1179PN1243FN2280
08.99~08.04 4200 1H-Z HZJ76K RN1604V PN1411 DN1225RN1976V PN1243FN2280FN1179 FN0642
01.07~ 4200 1H-Z HZJ76L RN1604V PN1411 RN1976V PN1243FN2280FN1179 FN0642
01.07~ 4200 1H-Z HZJ76R RN1604V PN1411 RN1976VDN1225 FN2280PN1243FN1179 FN0642
08.98~ 4200 1H-Z HZJ78L RN1604V PN1411 DN1225RN1976V PN1243FN2306FN1179FN2280 FN0642
08.98~ 4200 1H-Z HZJ78R RN1604V PN1411 RN1976V PN1243FN1179FN2306FN2280 FN0642
01.90~01.07 4200 1H-Z HZJ79 RN1604V PN1411 DN1225RN1976V FN2280PN1243FN1179 FN0642
08.99~09.17 4200 1H-Z HZJ79L RN1604V PN1411 DN1225RN1976V FN2306FN2280PN1243FN1179 FN0642
08.99~ 4200 1H-Z HZJ79R RN1604V PN1411 RN1976VDN1225 PN1243FN1179FN2280 FN0642
08.98~07.09 4500 1FZ-FE FZJ79L RN1604V PN1411 DN1225RN1976V FN2280PN1243FN1179 FN0642
01.07~09.23 4500 1VD-FTV VDJ76R RN1604V PN1411 RN1976VDN1225 PN1243FN1179FN2280 FN0642
01.07~ 4500 1VD-FTV VDJ78L RN1604V PN1411 RN1976V FN1179FN2280PN1243 FN0642
01.07~ 4500 1VD-FTV VDJ78R RN1604V PN1411 RN1976V FN2280PN1243FN1179 FN0642
01.07~ 4500 1VD-FTV VDJ79R RN1604V PN1411 RN1976V FN2306FN2280PN1243FN1179 FN0642
