ROTOR DISC » RN2623V

RN2623V

Specification

Type
Vented
Outter Ø
325
Num. of holes
6
Hole Ø:
12.5
Disc Thickness (Max)
20
Disc Thickness (Min)
18
Height
35.2
Centering Diameter
96.3
Pitch Circle Ø
139.7
Drum Ø:
166
Front/Rear
Rear
Structure Material
G3000

Cross Reference

HYUNDAI / KIA
58411-CG300
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HYUNDAI   »   Staria

08.24~ 1600 G4FT PDR24 RN2621VRN2620V PN6142 RN2623V PN6141
04.21~ 2200 D4HB PSZ21 WGN 9P LHD RN2621VRN2620V PN6142 RN2622VRN2623V PN6143PN6141
04.21~ 2200 D4HB PSZ21 WGN 9P RHD RN2621V PN6142 RN2623V PN6141
04.21~ 3500 G6DU PSZ21 RN2620VRN2621V PN6142 RN2622VRN2623V PN6143PN6141
