ROTOR DISC » RN2573V

Image Not Available

Specification

Type
Vented
Outter Ø
283
Num. of holes
5
Hole Ø:
13.2
Disc Thickness (Max)
22
Disc Thickness (Min)
20
Height
42.6
Centering Diameter
65.5
Pitch Circle Ø
108
Drum Ø:
151
Front/Rear
Front
Structure Material
G3000

Cross Reference

Chery
204000081AA
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHERY   »   Tiggo 4

01.18~07.19 1500 SQRE4G15B T17 RN2573V PN0838 RN2574 PN0846
10.19~ 1500 SQRE4G15B / SQRE4G15C T19 RN2573V PN0838 RN2558RN2574 PN0846 FN0810
01.18~07.19 1500 SQRE4T15B T17 RN2573V PN0838 RN2574 PN0846
01.18~07.19 2000 SQRD4G20 T17 RN2573V PN0838 RN2574 PN0846

CHERY   »   Tiggo 4 Pro

01.20~ SQRE4G15C T19FL RN2573V PN0838 RN2574 PN0846
01.20~ SQRE4T15C T19FL RN2573V PN0838 RN2574 PN0846

CHERY   »   Tiggo 5

01.18~ 2000 SQRD4G20 T21 RN2573V PN0838 RN2574 PN0846

KAIYI   »   X3

08.23~ SQRE4T15C RN2573V PN0838 RN2574 PN0846

OMODA (CHERY)   »   C5

10.22~ 1500 SQRE4T15C T19C RN2573V PN0838 RN2574 PN0846
