ROTOR DISC » RN2550V

RN2550V

Specification

Type
Vented
Outter Ø
290
Num. of holes
5
Disc Thickness (Max)
26
Height
47.8
Centering Diameter
69
Front/Rear
Front
Structure Material
G3000
Pitch Circle Ø
110
Hole Ø:
12.7
Disc Thickness (Min)
24.2
Drum Ø:
143

Cross Reference

CHANGAN
3501101-W03
CHANGAN
S101062-1202
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CHANGAN   »   CS35 Plus

03.21~ 1400 JL473ZQ9 SC7144 RN2550V PN0377 PN8813PN25003
06.18~ 1600 JL478QEP SC7164 RN2550V PN0377 PN8813PN25003
Copyright © 2003-2024 JNBK Corporation. All Rights Reserved

Exemption from liability: the catalog data is advisory and can be used for reference only
