PERFORMANCE ROTOR DISC » RN2525DSET

RN2525DSET

Specification

Type
Perforated / Vented
Outter Ø
323
Num. of holes
5
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
49.5
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
143
Front/Rear
Front
Structure Material
GG20
Structure Material
GG20
Type 1:
Direction Vented
Outter Ø
323
Num. of holes
5
Disc Thickness (Max)
30
Disc Thickness (Min)
28
Height
49.5
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
143
Front/Rear
Front

Cross Reference

TOYOTA
43512-14200
TOYOTA
4351214230
TOYOTA
4351614030
TOYOTA
4351614050
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Supra

05.93~08.02 3000 2JZ-GE JZA80 RN1150VRN2525DSET PN1324PN1360 RN1488V PN1363PN1361 FN0567
05.93~08.02 3000 2JZ-GE JZA80L RN2525DSETRN1150V PN1360PN1324 RN1488VRN2029V PN1361PN1363 FN0567
