ROTOR DISC » RN1943

RN1943

Specification

Type
Solid
Outter Ø
286
Num. of holes
5
Disc Thickness (Max)
10
Height
64.9
Centering Diameter
62
Pitch Circle Ø
114.3
Front/Rear
Rear
Drum Ø:
190
Disc Thickness (Min)
8.5
Structure Material
G3000
Hole Ø:
14.5

Cross Reference

TOYOTA
42431-06130
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Camry

01.06~09.11 2400 2AZ-FE ACV40L RN1241V PN0828PN1521 RN1943RN1432 PN1522PN0829 FN0633FN0675
01.06~07.12 2400 2AZ-FE ACV40R RN1241V PN0828PN1521 RN1432RN1943 PN1522PN0829 FN0675
09.11~09.17 3500 2GR-FE GSV50L RN1241V PN1521PN0828 RN1432RN1943 PN0829PN1522 FN0633

TOYOTA   »   Camry/Aurion

08.11~10.17 2500 2AR-FE ASV50L RN1241V PN0828PN1521 RN1943RN1432 PN1522PN0829 FN0633FN0675
10.11~10.17 2500 2AR-FE ASV50R RN1241V PN1521PN0828 RN1943 PN0829PN1522 FN0675FN0633
01.06~10.11 3500 2GR-FE GSV40L RN1241V PN0828PN1521 RN1943RN1432 PN0829PN1522 FN0633
10.06~10.11 3500 2GR-FE GSV40R RN1241V PN1521PN0828 RN1943 PN1522PN0829 FN0675FN0633
01.12~10.17 3500 2GRFE GSV50 RN1241V PN0828PN1521 RN1943 PN0829PN1522
