NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1942V

ROTOR DISC » RN1942V

Specification

Type

Vented

Outter Ø

281

Num. of holes

5

Disc Thickness (Max)

28

Height

58.5

Centering Diameter

62

Pitch Circle Ø

114.3

Drum Ø:

153

Front/Rear

Front

Structure Material

G3000

Disc Thickness (Min)

26

Cross Reference

TOYOTA

43512-0K041

TOYOTA

43512-0K130

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Hilux

02.05~12.15	2000	1TR-FE	TGN15R	RN1942V	PN1831	DN1203	FN2335
08.04~09.08	2500	2KD-FTV	KUN15R	RN1340V RN1942V	PN1831 PN1801	DN1203	FN2335
08.04~07.11	3000	5L-E	LAN15L	RN1340V RN1942V	PN1831	DN1203	FN2335

TOYOTA » Innova

08.04~03.16	2500	2KD-FTV	KUN40R	RN1942V RN1340V	PN1831	DN1204	FN2335
07.11~10.15	2700	2TR-FE	TGN41L	RN1942V	PN1831	DN1203	FN2335
07.11~10.15	2700	2TR-FE	TGN41R	RN1942V
