ROTOR DISC » RN1840V

RN1840V

Specification

Type
Vented
Outter Ø
296
Num. of holes
6
Disc Thickness (Max)
35
Height
90
Centering Diameter
126
Pitch Circle Ø
167
Drum Ø:
128.5
Disc Thickness (Min)
33
Structure Material
G3000
Front/Rear
Front
Hole Ø:
M14x1.5

Cross Reference

TOYOTA
43512-37060
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Dyna

05.95~05.99 3400 3B BU100 RN1265VRN1840V FN2296 FN2297FN2296 FN2298
08.97~05.99 3400 3B BU105 RN1840V PN1388PN1330 FN2297BL2329FN2329 FN2298
10.96~05.99 4100 15B-F BU137 RN1840V PN1388 FN2297 FN2298
08.97~05.99 4100 15BF BU107 RN1840V PN1388PN1330 BL2329FN2297FN2329 FN2298

TOYOTA   »   Dyna 200 / Toyoace G25

08.97~05.99 3400 3B BU145 RN1840V PN1330PN1388 FN2297BL2329FN2329 FN2298
10.96~05.99 4100 15B-F BU147 RN1840V PN1388PN1330 FN2329FN2297BL2329 FN2298
10.95~05.99 5300 J05C XZU130A RN1840V FN2329BL2329 FN2329 FN0039
