ROTOR DISC » RN1831V
Specification
Type
Vented
Outter Ø
312
Num. of holes
6
Disc Thickness (Max)
18
Height
102.5
Centering Diameter
106
Pitch Circle Ø
139.7
Front/Rear
Rear
Disc Thickness (Min)
16
Drum Ø:
210
Structure Material
G3000
Cross Reference
TOYOTA
42431-60080
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.90~09.92 | 4000 | 3F-E | FJ80G | RN1090V | PN1242 | RN1831V | PN1243 | FN0642 |
| 01.90~09.92 | 4000 | 3F-E | FJ80L | RN1090V | PN1242 | DN1222RN1831V | FN1179PN1243FN2280 | FN0642 |
| 01.90~09.92 | 4000 | 3F-E | FJ80R | RN1090V | PN1242 | DN1222RN1831V | FN2280FN1179PN1243 | FN0642 |
| 01.90~01.98 | 4200 | 1H-Z | HZJ80L | RN1090V | PN1242 | DN1223DN1222RN1831V | FN2280PN1243FN1179 | FN0642 |
| 01.90~08.92 | 4200 | 1H-Z | HZJ80R | RN1090V | PN1242 | RN1831VDN1223DN1222RN1157V | PN1243FN2280FN1179 | FN8905FN0642 |
| 01.90~08.92 | 4200 | 1HD-#T | HDJ80L | RN1066VRN1090V | PN1242 | RN1831VDN1222RN1157VDN1223 | FN2280PN1243FN1179 | FN0642 |
| 01.90~08.92 | 4200 | 1HD-#T | HDJ80R | RN1066VRN1090V | PN1242 | DN1222RN1157VRN1831VDN1223 | PN1243FN1179FN2280 | FN0642 |
