ROTOR DISC » RN2478V
Specification
Type
Vented
Outter Ø
325
Num. of holes
8
Hole Ø:
16.5
Disc Thickness (Max)
38
Disc Thickness (Min)
36.5
Height
89
Centering Diameter
118.2
Pitch Circle Ø
165.1
Front/Rear
Front
Structure Material
G3000
Cross Reference
GM
15718986
GM
15733625
GM
15942195
GM
18060215
GM
19175102
GM
19175166
GM
84587921
GM
89032236
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.16~ | 2800 | LWN | GG234 | RN2478V | PN0409 | PN0656 | FN0803 | |
| 09.17~ | 4300 | LV1 | GG234 | RN2478V | PN0409 | PN0656 | FN0803 | |
| 09.09~08.20 | 6000 | L96 | CG234 | RN2478V | PN0409 | PN0656 | FN0803 | |
| 09.09~08.20 | 6000 | LC8 | CG234# | RN2478V | PN0409 | PN0656 | FN0803 | |
| 01.09~ | 6000 | LY6 | CG234 | RN2478V | PN0409 | PN0656 | FN0803 |
