ROTOR DISC » RN2474V

RN2474V

Specification

Type
Vented
Outter Ø
321
Num. of holes
5
Hole Ø:
M14x1.5
Disc Thickness (Max)
35
Disc Thickness (Min)
33
Height
80.3
Centering Diameter
131
Pitch Circle Ø
172
Drum Ø:
133.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

TOYOTA
43512-37100
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Dyna

05.99~06.04 4600 S05C XZU362 RN2474V PN1330 DN1217 FN2329BL2329 FN0015
05.99~06.04 4600 S05C XZU362A RN2474V PN1330 DN1217 FN2329BL2329 FN0015
05.99~06.04 4600 S05C XZU362D RN2474V PN1330 DN1217 FN2329BL2329 FN0015
05.99~06.04 4600 S05C XZU372 RN2474V PN1330 DN1217 BL2329FN2329 FN0015
05.99~06.04 4900 S05D XZU371 RN2474V PN1330 DN1217 FN2329BL2329 FN0015
