ROTOR DISC » RN2473V

Specification

Type
Vented
Outter Ø
342
Num. of holes
6
Disc Thickness (Max)
22
Height
56
Front/Rear
Rear
Structure Material
G3000
Hole Ø:
16.1
Disc Thickness (Min)
20
Centering Diameter
90
Pitch Circle Ø
135
Drum Ø:
230

Cross Reference

FORD
7U2Z-2V026-G
FORD
7U2Z-2V026-GC
FORD
AL1Z-2C026-AA
FORD
AL1Z-2C026-B
FORD
CL1Z-2C026-A
FORD
G2MZ-2V026-ADA
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.14~06.17 3500 T35PDTD B7 RN2297V PN51003 RN2473V PN0609 FN0776
08.04~06.17 5400 T54USEM B7 RN2297V PN51003PN0416PN0608 RN2473V PN0609PN0620 FN0776
08.14~06.17 3500 T35PDTD B5 RN2297V PN51003 RN2473V PN0609 FN0776
08.04~08.14 5400 T54USEM B5 RN2297V PN0608PN0416PN51003 RN2473V PN0620PN0609 FN0776

Exemption from liability: the catalog data is advisory and can be used for reference only
