ROTOR DISC » RN2465

Specification

Type
Solid
Outter Ø
334
Num. of holes
5
Disc Thickness (Max)
11
Height
55.9
Pitch Circle Ø
120
Disc Thickness (Min)
9
Centering Diameter
70.1
Front/Rear
Rear
Structure Material
G3000

Cross Reference

HONDA
42510-SJC-A50
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
02.05~05.08 3500 J35Z4 YK1 RN1496V PN28003 RN2465 PN28004 FN0690
05.08~05.11 3500 J35Z4 YK1 RN1496V PN28003 RN2465 PN28004 FN0690
05.11~03.15 3500 J35Z5 YK1 RN1496V PN28003 RN2465 PN28004 FN0690

Exemption from liability: the catalog data is advisory and can be used for reference only
