ROTOR DISC » RN2435V

RN2435V

Specification

Type
Vented
Outter Ø
241
Num. of holes
4
Hole Ø:
12.5
Disc Thickness (Max)
18
Disc Thickness (Min)
16
Height
46
Centering Diameter
62.2
Pitch Circle Ø
100
Front/Rear
Front
Structure Material
G3000

Cross Reference

KIA
51712-G6000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

KIA   »   Picanto

06.20~01.23 1000 G3LA PG620 RHD RN2435VRN2159V PN0767PN0766 DN1460 FN0746

KIA   »   Picanto 17

04.17~01.21 1000 G3LA PG617 LHD RN2159VRN2435V PN0766PN0767 DN1460 FN0746PN0768
04.17~01.21 1200 G4LA JA RN2159VRN2435V PN0766PN0767 DN1460 PN0768FN0746
