ROTOR DISC » RN1729

Specification

Type
Solid
Outter Ø
302
Num. of holes
5
Disc Thickness (Max)
11
Height
64.2
Centering Diameter
63.6
Pitch Circle Ø
108
Front/Rear
Rear
Drum Ø:
186
Disc Thickness (Min)
9
Structure Material
G3000

Cross Reference

LAND ROVER
LR039935
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.06~10.14 2200 224DT / 200AQ / DW12 FA RN1589V PN0462W RN1729 PN0461PN0463 FN0708

Exemption from liability: the catalog data is advisory and can be used for reference only
