ROTOR DISC » RN1719V

RN1719V

Specification

Type
Vented
Outter Ø
328
Num. of holes
5
Disc Thickness (Max)
28
Height
73
Pitch Circle Ø
120
Front/Rear
Front
Centering Diameter
75
Drum Ø:
153
Disc Thickness (Min)
26.4
Structure Material
G3000

Cross Reference

BMW
34 10 6 787 490
BMW
34106879122
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

BMW   »   X3 sDrive 20 i

10.11~08.17 2000 N20B20A F25 RN1719V PN0558 RN1720V PN0546

BMW   »   X3 xDrive 20 d

04.14~08.17 2000 B47D20 F25 RN1719V PN0558 RN1720V PN0546
09.10~08.17 2000 N47D20C F25 RN1719V PN0558 RN1720V PN0546
06.14~10.17 2000 N47D20C WY32 JPN RHD RN1719V PN0558 RN1720V PN0546
09.10~03.14 2000 N47N F25 RN1719V PN0558 RN1720V PN0546

BMW   »   X3 xDrive 20 i

04.11~08.17 2000 N20B20A F25 RN1719V PN0558 RN1720V PN0546
06.12~08.17 2000 N20B20A F25 RN1719V PN0558 RN1720V PN0546

BMW   »   X3 xDrive 28 i

08.11~08.17 2000 N20B20A F25 RN1719V PN0558 RN1720V PN0546
04.12~08.17 2000 N20B20A F25 RN1719V PN0558 RN1720V PN0546
01.11~10.12 3000 N52B30A F25 RN1719V PN0558 RN1720V PN0546

BMW   »   X3 xDrive 30 d

04.11~08.17 3000 N57D30 F25 RN1719V PN0558 RN1720V PN0546

BMW   »   X3 xDrive 35 i

12.10~08.17 3000 N55B30A F25 RN1719V PN0558 RN1720V PN0546

BMW   »   X4 xDrive 20 d

04.14~03.18 2000 B47D20 F26 RN1719V PN0558 RN1720V PN0546
03.15~09.18 2000 B47D20A F26 RN1719V PN0558 RN1720V PN0546

BMW   »   X4 xDrive 20 i

04.14~03.18 2000 N20B20A F26 RN1719V PN0558 RN1720V PN0546

BMW   »   X4 xDrive 28 i

04.14~03.18 2000 N20B20A F26 RN1719V PN0558 RN1720V PN0546

BMW   »   X4 xDrive 35 i

04.14~03.18 3000 N55B30A F26 RN1719V PN0558 RN1720V PN0546
