ROTOR DISC » RN1686V

Specification

Type
Vented
Front/Rear
Front
Outter Ø
321
Num. of holes
5
Disc Thickness (Max)
30
Height
51
Centering Diameter
67.4
Pitch Circle Ø
120
Drum Ø:
160
Disc Thickness (Min)
28.6
Structure Material
G3000

Cross Reference

GM
13501308
GM
13501320
GM
13502214
GM
13579150
GM
23118055
GM
23118530
OPEL
05 69 064
OPEL
05 69 083
OPEL
05 69 422
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.12~05.16 3600 LFX 4G#69 RN1686V PN0839 RN1687V PN0840
01.15~ 3600 LGX P90D RN1686V PN0813SPN34002 PN51007
03.09~08.11 3600 LLT 1E#37 RN1686V PN34002PN0713 PN51007
01.10~01.18 2400 LAF 1L#26 RN1686V PN0839 RN2213V PN0479 FN0667
02.15~03.17 2400 LEA 1L#26 RN1686V PN34002PN0713 RN2213V PN0479 FN0667
03.13~02.20 3600 LFX 1GZ69 RN1686V PN0839 RN1687V PN0840
05.12~01.16 2000 LBS/ A20DTH RGB69 RN1686V PN0839 RN1685 PN0840
04.12~12.15 2000 LBS/ A20DTH V300 RN1686V PN34002 PN0581
01.12~01.17 2400 LE9 GA69 RN1684VRN1686V PN34002PN0713PN0839 RN1687VRN1685 PN0581PN0840
01.12~01.17 3000 LFW LTZ RN1686V PN0713PN34002 RN1687V PN0840
01.11~01.15 2400 LEA TL#26 RN1686V PN0839PN34002PN0713 RN2213V PN0479 FN0667
04.09~01.15 3000 LFW TL1 RN1686V PN0839 RN2213V PN0479 FN0667
03.08~12.17 2000 A20DTC M35 RN1686VRN1684V PN0839PN34002 RN1687VRN1685 PN0840
07.08~12.17 2000 A20DTH M68 RN1686V PN34002PN0713 RN1687V PN0840
07.08~12.17 2000 A20NHT G09 RN1686V PN34002PN0713 RN1687V PN0840

Exemption from liability: the catalog data is advisory and can be used for reference only
