ROTOR DISC » RN1683V

Specification

Type
Vented
Num. of holes
6
Outter Ø
315
Disc Thickness (Max)
23
Height
48
Centering Diameter
67.4
Pitch Circle Ø
120
Drum Ø:
201
Front/Rear
Rear
Disc Thickness (Min)
21.5
Structure Material
G3000

Cross Reference

GM
13501317
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.09~01.11 2800 LAU RN1662V PN51006 RN1683V PN51007 FN0753
01.09~04.16 3000 LF1 6NG26 RN1662V PN51006 RN1683V PN51007 FN0753
09.11~04.16 3600 LFX 6N1 RN1662V PN51006 RN1683V PN51007 FN0753

Exemption from liability: the catalog data is advisory and can be used for reference only
