ROTOR DISC » RN2415

Specification

Type
Solid
Outter Ø
280
Num. of holes
4
Hole Ø:
13.2
Disc Thickness (Max)
9.5
Disc Thickness (Min)
7.5
Height
35.5
Centering Diameter
55
Pitch Circle Ø
100
Drum Ø:
124.8
Front/Rear
Rear
Structure Material
G3000

Cross Reference

CHRYSLER
68313 167AA
FIAT
6000612254
MAZDA
N251-26-251
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.16~ 1400 552 53 268 348 ABARTH RN2158V PN0636PN5817 RN2415 PN5813
01.19~ 2000 PE ND RN2158V PN0636PN5817 RN2415 PN5813
05.15~ 2000 PEX# ND RN2158V PN5817 RN2415 PN5813

Exemption from liability: the catalog data is advisory and can be used for reference only
