ROTOR DISC » RN2406V

Specification

Type
Vented
Outter Ø
375
Num. of holes
5
Hole Ø:
15.3
Disc Thickness (Max)
32
Disc Thickness (Min)
29.4
Height
54.6
Centering Diameter
67
Pitch Circle Ø
112
Drum Ø:
156.3
Front/Rear
Front
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
A 164 421 06 12
MERCEDES-BENZ
A 164 421 15 12
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.09~08.12 3000 OM 642.820 X164 RN2406VRN1704V PN0464PN0500 RN1538V PN0507 FN0638
09.06~05.09 3000 OM 642.940 X164 RN2406VRN1704V PN0500PN0464 RN1538V PN0507 FN0638
09.06~05.09 4000 OM 629.912 X164 RN2406V PN0464 RN1538V PN0507 FN0638
05.09~08.12 4000 OM 629.912 X164 RN2406V PN0464 RN1538V PN0507 FN0638
09.06~08.12 4700 M 273.923 X164 RN2406VRN1704V PN0464PN0500 RN1538V PN0507 FN0638
09.06~12.12 5500 M 273.963 X164 RN1704VRN2406V PN0464PN0500 RN1538V PN0507 FN0638
12.07~12.11 5500 M 273.963 W164 RN2406V PN0464 RN1538V PN0507 FN0638
07.07~12.14 5500 M 273.963 W251 RN1704VRN2406V PN0464PN0500 RN1538V PN0507 FN0638

Exemption from liability: the catalog data is advisory and can be used for reference only
