ROTOR DISC » RN1674V

Specification

Type
Vented
Num. of holes
5
Pitch Circle Ø
114.3
Outter Ø
345
Height
38.5
Centering Diameter
68
Disc Thickness (Max)
19
Drum Ø:
201
Disc Thickness (Min)
17.5
Structure Material
G3000

Cross Reference

FORD
DG1Z-2C026-A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.15~08.19 2300 T23HD0D TUB RN1673VRN1792V PN0623PN0622 RN1676RN1674V PN0698
11.10~03.19 3500 T35PDED TUB RN1792VRN1673V PN0622PN0623 RN1676RN1674V PN0698
03.13~04.19 3500 T35PDED TWJ RN1673V PN0623 RN1674V PN0698
09.12~03.19 3500 T35PDTD TUB RN1673V PN0623 RN1674V PN0698
03.13~04.19 3500 T35PDTD TWJ RN1673V PN0623 RN1674V PN0698
02.12~10.19 3500 T35PDED P3 RN1673V PN0623 RN1674V PN0698
05.08~05.16 3700 C37PDED LE RN1673VRN1792V PN0622PN0623 RN1676RN1674V PN0698

Exemption from liability: the catalog data is advisory and can be used for reference only
