ROTOR DISC » RN1657
Specification
Type
Solid
Outter Ø
299
Num. of holes
5
Disc Thickness (Max)
10.2
Height
68
Centering Diameter
85
Front/Rear
Rear
Pitch Circle Ø
112
Drum Ø:
190
Disc Thickness (Min)
8.5
Structure Material
G3000
Cross Reference
SSANGYONG
48401-09002
SSANGYONG
4840109000
SSANGYONG
4840109001
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 10.05~01.11 | 2000 | D20DT | C100 | RN1620V | PN0103 | RN1657DN1689 | PN0440FN1879 | FN0696 |
| 07.06~01.12 | 2300 | G23D | C100 LHD | RN1620V | PN0103 | DN1689RN1657 | FN1879PN0440 | FN0696 |
| 10.05~01.12 | 2300 | G23D | C100 RHD | RN1620V | PN0103 | DN1689RN1657 | FN1879PN0440 | FN0696 |
| 04.06~03.12 | 2000 | D20DT | Q100 LHD | RN1620V | PN0103 | RN1657DN1689 | PN0440FN1879 | FN0696 |
| 04.06~03.12 | 2000 | D20DT | Q100 RHD | RN1620V | PN0103 | RN1657DN1689 | PN0440FN1879 | FN0696 |
| 03.12~ | 2000 | D20DTR | Q150 | RN1620V | PN0103 | DN1689RN1657 | PN0440FN1879 | FN0696 |
| 07.16~ | 2200 | D22DTR | Q160 | RN1620V | PN0103 | RN1657 | FN1879PN0440 | FN0696 |
| 03.12~ | 2300 | G23D | Q150 | RN1620V | PN0103 | DN1689RN1657 | FN1879PN0440 | FN0696 |
| 01.05~01.15 | 2000 | D20DT | 5DR SUV | RN1620V | PN0103 | RN1657RN1798VDN1689 | FN1879PN0440 | FN0696 |
| 04.07~01.12 | 2000 | D20DT | 5DR SUV DOM 7P | RN1620V | PN0103 | RN1798VDN1689RN1657 | FN1879PN0797PN0440 | FN0696 |
| 01.05~01.15 | 2000 | D20DT | 5DR SUV EU | RN1620V | PN0103 | RN1657DN1689RN1798V | FN1879PN0440 | FN0696 |
| 01.05~01.15 | 2300 | G23D | 5DR SUV | RN1620V | PN0103 | DN1689RN1657 | PN0440FN1879 | FN0750FN0696 |
| 05.12~10.17 | 2000 | D20DTR | Y290 | RN1620V | PN0103 | RN1657RN1798V | PN0440PN0797 | FN0696 |
| 06.12~10.17 | 2200 | D22DTR | Y290 | RN1620V | PN0103 | RN1657RN1798V | PN0797PN0440 | FN0750 |
| 02.06~07.12 | 2700 | D27DT | Y250 | RN1620V | PN0103 | RN1657RN1798V | PN0797PN0440 | FN0696 |
| 01.12~10.17 | 2700 | D27DT | Y290 | RN1620V | PN0103 | RN1798VRN1657 | PN0797PN0440 | FN0696FN0750 |
| 03.06~07.12 | 3200 | G32D | Y250 | RN1620V | PN0103 | RN1657 | PN0440 | FN0750 |
