ROTOR DISC » RN1650V

RN1650V

Specification

Type
Vented
Outter Ø
325
Num. of holes
5
Disc Thickness (Max)
18
Height
56.7
Centering Diameter
72
Pitch Circle Ø
114.3
Front/Rear
Rear
Drum Ø:
190
Disc Thickness (Min)
16
Structure Material
G3000

Cross Reference

MAZDA
L232-26-251
MAZDA
L232-26-251A
MAZDA
L232-26-251B
MAZDA
L232-26-251C
MAZDA
TD11-26-251
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MAZDA   »   CX-7

06.09~12.12 2200 R2AA AEES02 RN1503V PN3813 RN1650V PN5814 FN0696

MAZDA   »   CX-9

10.06~12.15 3500 CYC4 TB RN1503V PN3813 RN1650V PN5814 FN0696
10.06~07.09 3700 CAY TV01 RN1503V PN3813 RN1650V PN5814 FN0696
07.09~12.12 3700 CAY TV02 RN1503V PN3813 RN1650V PN5814 FN0696
11.12~12.15 3700 CAY TV03 RN1503V PN3813 RN1650V PN5814 FN0696

MAZDA   »   MPV

01.06~04.16 2300 L3-V# LY3P RN1501VRN1503V PN3813 RN1650VRN1502V PN5814 FN0696
