BRAKE SHOE » FN7734

Specification

Radius
90
Width
30
Thickness
3
Pcs In Set
4

Cross Reference

KASHIYAMA
K7734
SUBARU
7251-78141
SUBARU
7251-78151
SUBARU
7251-78161
SUBARU
7251-78450
SUBARU
7251-78460
SUBARU
7251-78470
SUBARU
7251-78490
SUBARU
7251-78500
SUBARU
7251-78510
SUBARU
7251-93180
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.83~06.94 1200 EF12 KJ8 PN2080 FN7734
05.93~11.98 1200 EF12 KJ8 PN7251 FN7734
09.82~09.88 550 EK23 KR1 FN7737FN7723PN2080FN7720 FN7743FN7734
09.87~08.88 550 EK23 KR6 PN2080 FN7724FN7734
02.84~09.88 550 EK23 KT1 PN2080FN7720FN7737FN7723 FN7734FN7743

Exemption from liability: the catalog data is advisory and can be used for reference only
