NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN1633V

ROTOR DISC » RN1633V

Specification

Type

Vented

Num. of holes

6

Disc Thickness (Max)

15

Outter Ø

291

Height

67.2

Centering Diameter

108

Pitch Circle Ø

139.7

Front/Rear

Rear

Disc Thickness (Min)

14

Drum Ø:

190

Structure Material

G3000

Hole Ø:

14.5

Cross Reference

TOYOTA

42431-26170

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Granvia / Grand Hiace

10.95~05.02	3000	1KZ-TE	KCH16W	RN1304V	PN1237	RN1633V DN1252	FN2330 PN1363	FN0567
05.97~05.02	3400	5VZ-FE	VCH16W	RN1304V	PN1237	RN1633V	PN1363	FN0567

TOYOTA » Hiace Regius Touring

01.97~05.02	2700	3RZ-FE	RCH47W	RN1304V	PN1237	RN1633V	PN1363	FN0567
04.97~09.99	3000	1KZ-TE	KCH46G	RN1304V	PN1237	RN1633V	PN1363
04.97~05.02	3000	1KZ-TE	KCH46W	RN1304V	PN1237	RN1633V	PN1363	FN0567
