PERFORMANCE ROTOR DISC » RN1120DSET
Specification
Type 1:
Direction Vented
Outter Ø
302
Num. of holes
5
Disc Thickness (Max)
18
Height
46.3
Centering Diameter
62
Pitch Circle Ø
114.3
Drum Ø:
156
Variation
Cross Reference
BENDIX
562119B
TOYOTA
43512-42010
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.96~05.00 | 2000 | 3S-#E | SXA10W | RN1120V | PN1322 | DN1211RN1207 | FN2333PN1424 | FN0567 |
| 04.95~05.00 | 2000 | 3S-#E | SXA11 | RN1120V | PN1322 | RN1207DN1211 | PN1424FN2333 | |
| 01.94~05.00 | 2000 | 3S-FE | SXA10G | RN1120V | PN1322 | DN1211 | FN2333 | |
| 04.95~08.00 | 2000 | 3S-FE | SXA11L | RN1120V | PN1322 | DN1211 | FN2333 | |
| 04.95~05.00 | 2000 | 3S-FE | SXA11R | RN1120V | PN1322 | DN1211 | FN2333 | |
| 09.97~05.00 | 2000 | 3S-FE | SXA15G | RN1120V | PN1322 | DN1211 | FN2333 | |
| 02.96~08.00 | 2000 | 3S-FE | SXA15L | RN1120V | PN1322 | DN1211 | FN2333 | |
| 09.97~05.00 | 2000 | 3S-FE | SXA16G | RN1120V | PN1322 | DN1211 | FN2333 | |
| 02.96~08.00 | 2000 | 3S-FE | SXA16L | RN1120V | PN1322 | DN1211 | FN2333 | |
| 01.93~01.00 | 2000 | 3SFE | SXA10L | RN1120V | PN1322 | DN1211 | FN2333 |
