ROTOR DISC » RN1504V

Specification

Type
Vented
Outter Ø
285.8
Num. of holes
5
Disc Thickness (Max)
35
Height
91
Centering Diameter
114
Pitch Circle Ø
140
Drum Ø:
150
Front/Rear
Front
Structure Material
G3000

Cross Reference

NISSAN
40206-0T600
NISSAN
40206-0T601
NISSAN
D0206-0T600
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.91~11.95 4200 FD42 DG2S41 RN1504V PN2368 FN4451BL1055
10.91~06.95 4200 FD42 DG2H41 RN1504VRN1359V PN2368FN4451 BL1055FN1202 FN1244
10.91~06.95 4200 FD42 DG7YH41 RN1504V PN2368 FN4451BL1055
10.91~08.95 4200 FD42 G4H41 RN1504V PN2368FN4451 FN4451BL1055 FN1244
10.91~08.95 4200 FD42 G4S41 RN1504V PN2368FN4451 FN4451BL1055 FN1244
01.92~12.95 4600 FD46 H41 RN1504V FN4451PN2368 FN4451BL1055 FN1244
05.88~02.99 4200 TD42 RAW40 RN1504V FN1152PN2368 BL1055FN1152FN4451 FN8802
04.99~08.04 4200 TD42 W41 RN1504V PN4464PN2802PN2368 BL1055FN4451 FN1244
05.88~02.99 4200 TD42# RGW40 RN1504V PN2368 BL1055FN4451 FN1244

Exemption from liability: the catalog data is advisory and can be used for reference only
