ROTOR DISC » RN1588V

RN1588V

Specification

Type
Vented
Outter Ø
300
Num. of holes
5
Disc Thickness (Max)
28
Height
58.5
Centering Diameter
67
Pitch Circle Ø
112
Front/Rear
Front
Drum Ø:
153
Hole Ø:
15
Disc Thickness (Min)
25
Structure Material
G3000

Variation

RN1588DSET[NiBK]

Cross Reference

MERCEDES-BENZ
A 447 421 05 12
MERCEDES-BENZ
A 447 421 05 12 07
MERCEDES-BENZ
A 639 421 00 12
MERCEDES-BENZ
A 639 421 02 12
MERCEDES-BENZ
A 639 421 03 12
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MERCEDES-BENZ   »   116VTS/L4X2 3200

03.15~ 2100 OM 651.950 W477 RN1588V PN0410W RN2240 PN0654 FN0694

MERCEDES-BENZ   »   Metris

01.15~07.23 2000 M 274.920 W447 RN1588V PN0410W RN2240 PN0654 FN0694

MERCEDES-BENZ   »   V 109 D

09.03~10.10 2000 OM 646 W639 RN1588V PN0406W RN1559 PN0407W

MERCEDES-BENZ   »   V 110 D

09.10~ 2100 OM 651 W639 RN1588V PN0406W RN1559 PN0407W

MERCEDES-BENZ   »   V 111 D

09.03~ 2200 OM 646.982 W639 RN1588V PN0410W RN1559 PN0407W FN0694

MERCEDES-BENZ   »   V 113 D

09.10~ 2100 OM 651.940 W639 RN1588V PN0406WPN0410W RN1559 PN0407W FN0694

MERCEDES-BENZ   »   V 114

08.14~ 2200 OM 651.950 W447 RN1588V PN0410W RN2240 PN0654 FN0694

MERCEDES-BENZ   »   V 115 D

09.03~ 2100 OM 646 W639 RN1588V PN0406W RN1559 PN0407W

MERCEDES-BENZ   »   V 116 D

01.10~ 2200 OM 651.940 W639 RN1588V PN0410W RN1559 PN0407W FN0694

MERCEDES-BENZ   »   V 122

09.10~ 3200 M 112.951 W639 RN1588V PN0406W RN1559 PN0407W

MERCEDES-BENZ   »   V 220 D

04.14~ 2200 OM 651.950 W447 RN1588V PN0410W RN2240 PN0654 FN0694

MERCEDES-BENZ   »   Viano

09.03~ 2000 OM 646 W639 RN1588V PN0410W RN1559 PN0407W FN0694
01.03~ 2200 W639 RN1588V PN0406W RN1559 PN0407W
04.06~10.10 2200 OM 642.890 W639 RN1588V PN0410W RN1559 PN0407W FN0694
09.03~ 2200 OM 651 W639 RN1588V PN0410W RN1559 PN0407W FN0694
01.03~ 3000 M 112 W639 RN1588V PN0406W RN1559 PN0407W
01.03~ 3200 W639 RN1588V PN0406W RN1559 PN0407W
09.03~10.10 3200 M 112 W639 RN1588V PN0410W RN1559 PN0407W
