ROTOR DISC » RN2386V

Specification

Type

Vented

Outter Ø

320

Num. of holes

5

Hole Ø:

13.7

Disc Thickness (Max)

25

Disc Thickness (Min)

23

Height

48.5

Centering Diameter

72

Pitch Circle Ø

114.3

Drum Ø:

148

Front/Rear

Front

Structure Material

G3000

Cross Reference

AKEBONO

BN-1122

MAZDA

B37F-33-25X

MAZDA

B37F-33-25XA

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

MAZDA » Axela

06.06~05.09	2300	L3-VDT	BK3P	RN1194V RN2386V	PN0365 PN0352	RN1373	PN2702
06.09~09.11	2300	L3-VDT	BL3FW	RN2386V	PN0352	RN1373	PN2702
09.11~11.13	2300	L3-VDT	BL3FW	RN2386V	PN0365 PN0352	RN1373	PN2702

MAZDA » Mazda 3

07.06~03.09	2300	L3-VDT	5DR HB US	RN2386V	PN0352	RN1373	PN2702
03.06~03.09	2300	L3-VDT	ABBA11 HB	RN2386V	PN0352	RN1373	PN2702
01.03~03.09	2300	L3-VDT	BK	RN2386V	PN0352	RN1373	PN2702
01.09~11.13	2300	L3-VDT	BL HB	RN2386V	PN0352	RN1373	PN2702
