NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2366V

ROTOR DISC » RN2366V

Specification

Type

Vented

Outter Ø

280

Num. of holes

5

Disc Thickness (Max)

25

Height

48.4

Centering Diameter

69

Pitch Circle Ø

114.3

Front/Rear

Front

Structure Material

G3000

Hole Ø:

12.5

Disc Thickness (Min)

23

Drum Ø:

143.3

Cross Reference

HYUNDAI / KIA

51712-AA000

HYUNDAI / KIA

51712-AT500

KIA

51712-AT500

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

HYUNDAI » Avante / Elantra

04.20~

1600

G4FM

P0A20 DOM

RN2366V

PN6131

RN2233

PN6132

HYUNDAI » Elantra

03.20~	1600	G4FG	P0A20 RHD	RN2366V	PN6131	RN2233	PN6132
03.20~	1600	G4FM	RP0A20 SG	RN2366V	PN6131	RN2233	PN6146 PN6132
06.23~	1600	G4FP	CN7	RN2366V	PN6131	RN2233	PN6132 PN6146
03.20~	2000	G4NL	RP0A20	RN2366V	PN6131	RN2233	PN6132 PN6146

KIA » Niro

07.21~		EM	P0T21	RN2366V	PN6131	RN2272	PN6121
07.21~	1600	G4LL	P0T21 RHD SG	RN2366V	PN6131	RN2272	PN6121
