ROTOR DISC » RN1541V
Specification
Type
Vented
Outter Ø
255
Num. of holes
5
Disc Thickness (Max)
22
Height
49.2
Centering Diameter
55.2
Pitch Circle Ø
100
Front/Rear
Front
Drum Ø:
131
Disc Thickness (Min)
20
Structure Material
G3000
Cross Reference
TOYOTA
43512-47030
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.03~12.11 | 1500 | 1NZ-FXE | NHW20 | RN1541V | PN1472 | DN1208DN1233 | FN2342FN2403 | FN0614 |
| 08.03~12.11 | 1500 | 1NZ-FXE | NHW20 | RN1541V | PN1472 | DN1208DN1233 | FN2403FN2342 | FN0614 |
| 08.03~12.11 | 1500 | 1NZ-FXE | NHW20L | RN1541V | PN1472 | DN1233DN1208RN1440 | PN1431PN1454FN2342 | FN0614 |
| 08.03~12.11 | 1500 | 1NZ-FXE | NHW20R | RN1541V | PN1472 | DN1233RN1440DN1208 | FN2342PN1431 | FN0614 |
