ROTOR DISC » RN2349

Specification

Type
Solid
Outter Ø
239
Num. of holes
4
Disc Thickness (Max)
9
Disc Thickness (Min)
8
Height
33.3
Centering Diameter
61
Pitch Circle Ø
100
Front/Rear
Rear
Structure Material
G3000

Cross Reference

HONDA
42510-TZE-J00
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.19~ 1300 L13B GR1 RN2348V PN8868 RN2349 PN8821
10.19~ 1300 L13B GR2 RN2348V PN8868 RN2349 PN8821
10.19~ 1500 LEB GR3 RN2348V PN8868 RN2349 PN8821
02.20~ 1500 LEB8 GR3 RN2348V PN8868 RN2349 PN8821

Exemption from liability: the catalog data is advisory and can be used for reference only
