ROTOR DISC » RN2334

Specification

Type
Solid
Outter Ø
302
Num. of holes
5
Hole Ø:
15.6
Disc Thickness (Max)
12
Disc Thickness (Min)
10
Height
42.9
Centering Diameter
63.6
Pitch Circle Ø
108
Drum Ø:
141
Front/Rear
Rear
Structure Material
G3000

Cross Reference

VOLVO
31423721
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
05.19~ 2000 B4204T23 224 RN2258V PN0747 RN2334 PN0892
03.16~ 2000 B 4204 T27 SDN RHD RN1952VRN2258V PN0747PN0696 RN1930VRN2334 PN0650PN0892

Exemption from liability: the catalog data is advisory and can be used for reference only
