NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2306V

ROTOR DISC » RN2306V

Specification

Type

Vented

Outter Ø

340

Num. of holes

5

Hole Ø:

14.5

Disc Thickness (Max)

38

Disc Thickness (Min)

35

Height

49.3

Centering Diameter

62

Pitch Circle Ø

114.3

Drum Ø:

174

Front/Rear

Front

Structure Material

G3000

Cross Reference

SUZUKI

T4351-24815

TOYOTA

43512-0E070

TOYOTA

43512-48150

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

SUZUKI » Across

06.20~

2500

A25AFXS

A5Z

RN2306V

PN1869

RN2253V

PN1868
