ROTOR DISC » RN2285V

RN2285V

Specification

Type
Vented
Outter Ø
330
Num. of holes
5
Hole Ø:
15.1
Disc Thickness (Max)
32
Disc Thickness (Min)
28
Height
58.4
Centering Diameter
67
Pitch Circle Ø
112
Drum Ø:
153.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

MERCEDES-BENZ
A 447 421 00 12
MERCEDES-BENZ
A 447 421 00 12 07
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

MERCEDES-BENZ   »   V 116 D

11.14~03.23 2100 OM 651.950 W447 RN2285V PN0653 RN2240 PN0654 FN0694

MERCEDES-BENZ   »   V 220 D

09.19~ 2200 OM 651.950 447.813 RN2285V PN0653 RN2240 PN0654 FN0694
02.19~ 2200 OM 654.920 447.813 RN2285V PN0653 RN2240 PN0654 FN0694

MERCEDES-BENZ   »   V 250 D

04.14~ 2200 OM 651.950 W447 RN2285V PN0653 RN2240 PN0654
